WordPress Reference Architecture

A practical, layered view of WordPress as a platform, focused on Blocksy child themes as the customization vector. Written for engineers who need to make non-trivial changes to a Blocksy-based site without forking the parent, without breaking updates, and without painting themselves into a corner.

---

1. Overview

WordPress is a PHP/MySQL CMS organised around three coarse layers — core, plugins, theme — orchestrated by a request lifecycle that fires hundreds of action and filter hooks along the way. Blocksy is a popular Gutenberg-first theme with a deep configuration surface: a Customizer-driven header/footer builder, content-area modules, a custom-properties-based design system, the Blocksy Companion plugin that ships extensions, and an extensive hook API.

A child theme is the WordPress-blessed customization vector — a tiny package that declares Blocksy as its parent and selectively overrides theme.json, templates, assets, and hook callbacks without ever editing the parent. Parent updates ship cleanly, customizations live in version control, and the surface you maintain stays small.

---

2. Design Principles

Principle	What it means in practice
Hooks over template overrides	Hooks survive parent updates; template copies need re-syncing on major releases
Configuration over code	Use the Customizer and theme.json before reaching for PHP
Composition over forking	Add to Blocksy; don’t replace it. If you need to replace large chunks, pick a different parent
One source of truth per token	A design token (colour, font) lives in either Customizer or theme.json — never both
Version-controlled child, untouched parent	Parent and plugins are deployable artefacts; only the child theme carries your code
Conditional everything	Enqueue assets, run hooks, register CPTs only where needed
Escape on output, sanitize on input	The two non-negotiable rules of WordPress PHP

---

3. The Stack

WordPress sits on a conventional LEMP (or LAMP) stack. The child theme operates at the application layer but its decisions reach down (database queries, asset bytes) and up (caching, edge).

Layer	Component	What lives here
Edge	Cloudflare / CDN / WAF	TLS termination, DDoS, edge caching
Web server	Nginx or Apache	Static assets, reverse proxy to PHP-FPM
App server	PHP-FPM	WordPress execution
WP Core	wp-includes, wp-admin	Loader, query engine, rewrite, options API, hooks
MU-plugins	wp-content/mu-plugins	Always-on, can’t be disabled from the dashboard
Plugins	wp-content/plugins	Including Blocksy Companion
Parent theme	wp-content/themes/blocksy	Templates, hooks, design system, Customizer panels
Child theme	wp-content/themes/blocksy-child	Your overrides
Object cache	Redis / Memcached	Persistent options, transients, query cache
Database	MySQL / MariaDB	Posts, options, terms, meta
Storage	Local FS or S3-compatible	uploads/, media

---

4. Request Lifecycle — Where the Child Theme Intercepts

A typical page render flows through:

1. Web server routes to PHP-FPM
2. index.php → wp-blog-header.php → wp-load.php → wp-config.php → wp-settings.php
3. MU-plugins load, then active plugins load
4. Parent theme functions.php loads, then child theme functions.php loads
5. after_setup_theme → init → wp_loaded
6. Request parsing — parse_request → parse_query → pre_get_posts → main query
7. template_redirect → template_include — template resolution
8. Render — wp_head, header, content (blocks/templates), footer, wp_footer
9. Shutdown, response sent

The child theme can attach behaviour at any of these stages. The key intercept points:

Stage	Hook	Use for
Theme setup	after_setup_theme	add_theme_support, image sizes, nav menus
Asset registration	wp_enqueue_scripts	Stylesheets and scripts (front-end)
Editor assets	enqueue_block_editor_assets	Editor-side styling and scripts
Query shaping	pre_get_posts	Modify main query before it runs
Template choice	template_include	Force a template for a given request
Render hooks	blocksy:*, wp_head, wp_footer, content filters	Inject markup, modify output
Shutdown	shutdown	Logging, cache warming

---

5. Blocksy at a Glance

What the parent gives you out of the box:

Capability	Where it lives
Header builder	Customizer → Header
Footer builder	Customizer → Footer
Content area design controls	Customizer → per content type (single, archive, page, WooCommerce)
Design tokens	Inline <style> from Customizer + theme.json
Blocksy Companion plugin	Extensions (Sticky Header, Trending, Cookies Consent, Demo Install, etc.)
Hook API	blocksy:* action and filter prefix
WooCommerce integration	Dedicated templates and Customizer panels
Pro features	Mega Menu, Local Google Fonts, Conditional Headers, Advanced Hooks, White Label

Worth knowing: Blocksy is hybrid — not full-site-editing in the strict sense. Header, footer, and loops are Blocksy PHP renderers driven by Customizer settings; post content uses the block editor. Block templates work as overrides but are not the primary configuration surface. If you want a strictly FSE workflow, pick a strictly FSE parent.

---

6. Child Theme Anatomy

6.1 Minimum Viable Child

blocksy-child/
├── style.css        ← required, with Template: blocksy header
└── functions.php    ← enqueue parent + child styles

style.css header:

css

/*
Theme Name: My Blocksy Child
Template: blocksy
Version: 1.0.0
Text Domain: blocksy-child
*/

functions.php minimum:

php

<?php
defined('ABSPATH') || exit;

add_action('wp_enqueue_scripts', function () {
    wp_enqueue_style(
        'blocksy-parent',
        get_template_directory_uri() . '/style.css'
    );
    wp_enqueue_style(
        'blocksy-child',
        get_stylesheet_uri(),
        ['blocksy-parent'],
        wp_get_theme()->get('Version')
    );
});

6.2 Recommended Structure

blocksy-child/
├── style.css              ← theme header + a couple of resets
├── functions.php          ← bootstraps include files only
├── theme.json             ← design token overrides
├── screenshot.png         ← 1200×900, for the Themes screen
├── inc/
│   ├── enqueue.php        ← asset registration
│   ├── hooks.php          ← action/filter callbacks
│   ├── shortcodes.php
│   ├── cpt.php            ← custom post types & taxonomies
│   └── customizer.php     ← child-specific Customizer additions
├── templates/             ← FSE block template overrides
│   └── single.html
├── parts/                 ← block template parts
├── patterns/              ← reusable block patterns
├── woocommerce/           ← WooCommerce template overrides
└── assets/
    ├── css/
    ├── js/
    ├── fonts/
    └── images/

functions.php loader pattern:

php

<?php
defined('ABSPATH') || exit;

foreach (['enqueue', 'hooks', 'shortcodes', 'cpt', 'customizer'] as $f) {
    require_once get_stylesheet_directory() . "/inc/{$f}.php";
}

---

7. Customization Vectors — Decision Matrix

The single most useful table in this document. When you want to change something, this is the lookup.

Goal	Best vector	Notes
Change a colour or font token	theme.json or Customizer → Colors/Typography	theme.json wins for block editor parity
Set defaults on a block (e.g. all Buttons rounded)	theme.json styles.blocks.core/button	Survives editor edits as defaults
Add a section after the header	add_action('blocksy:header:after', ...)	Blocksy hook
Add a section before the post title	add_action('blocksy:single:title:before', ...)
Change archive card layout	Customizer → Archive → Card Type	Often no code needed
Override a single template	templates/single.html (block) or PHP copy	Try the hook first
Override WooCommerce single product	woocommerce/single-product.php	Standard WC override path
Register a custom post type	inc/cpt.php with register_post_type
Add a custom block	block.json + register_block_type	Heavier; consider ACF Blocks for content-team UX
Add a block pattern	patterns/my-pattern.php	Auto-discovered
Modify rendered HTML	Filter (the_content, blocksy:*)	Don’t break nested structure
Conditional logic per page	is_singular(), is_archive(), etc. inside hooks
Brand the admin	Companion → White Label (Pro)

---

8. The Hook System

WordPress’s plugin API splits into actions (do something at a point) and filters (modify a value passing through a point). Blocksy adds its own prefix-namespaced hooks; combined with core hooks, they cover most customization without template overrides.

8.1 Notable Blocksy Action Hooks

Hook	Fires
blocksy:header:before / :after	Around the header
blocksy:footer:before / :after	Around the footer
blocksy:content:top / :bottom	Around the main content area
blocksy:single:before / :after	Around single post/page content
blocksy:single:title:before / :after	Around the post title
blocksy:single:content:top / :bottom	Inside the content wrapper
blocksy:loop:posts:before / :after	Around the loop on archives
blocksy:archive:cards:title:before / :after	Around archive card titles
blocksy:woocommerce:product-single:before	WooCommerce hooks

8.2 Pattern — Adding a Pre-Header Notice

php

// inc/hooks.php
add_action('blocksy:header:before', function () {
    if (!is_front_page()) {
        return;
    }
    echo '<div class="pre-header-notice">'
       . esc_html__('Free shipping over €50', 'blocksy-child')
       . '</div>';
});

8.3 Pro Advanced Hooks

Blocksy’s Pro Advanced Hooks extension lets non-developers attach content (HTML, shortcodes, blocks) to hooks via the admin. Useful for content teams; for engineering work prefer code in inc/hooks.php under version control so it ships through CI.

---

9. theme.json — The Design System

theme.json is the modern declarative way to configure the block editor’s design system. Resolution hierarchy:

Layer	Wins over	Source
User Global Styles	All below	Saved via Site Editor
Child theme.json	Parent + core	Your repo
Parent theme.json	Core defaults	Blocksy’s theme.json
WordPress core	Nothing	wp-includes/theme.json

Minimal child override:

json

{
  "$schema": "https://schemas.wp.org/trunk/theme.json",
  "version": 2,
  "settings": {
    "color": {
      "palette": [
        { "slug": "primary", "name": "Primary", "color": "#003594" },
        { "slug": "accent",  "name": "Accent",  "color": "#E4002B" }
      ]
    }
  },
  "styles": {
    "blocks": {
      "core/button": {
        "border": { "radius": "4px" }
      }
    }
  }
}

Caveat about Blocksy specifically. Blocksy also exposes design tokens via its Customizer and emits inline CSS custom properties (--theme-palette-color-1, --theme-font-family, etc.). For Blocksy-controlled regions (header, footer, loops) Customizer settings often win; for block content theme.json wins. Choose one source per token and stick to it — mixing leads to spec-by-debugger.

---

10. Template Hierarchy and Overrides

Simplified resolution for a single post:

single-{post-type}-{slug}.php
  → single-{post-type}.php
    → single.php
      → singular.php
        → index.php

With block templates, parallel templates/*.html resolution runs first.

Override discipline:

1. Copy the parent template into the child
2. Comment the parent version you copied from
3. Diff and re-copy on major Blocksy releases
4. Prefer hooks where a hook gives the same surface

WooCommerce overrides follow the same path: copy from wp-content/plugins/woocommerce/templates/ into your child’s woocommerce/ directory.

---

11. Asset Pipeline

Asset	Mechanism
Front-end stylesheet	wp_enqueue_style in wp_enqueue_scripts
Front-end script	wp_enqueue_script with dependencies, in_footer => true
Editor style	enqueue_block_editor_assets
Per-block style	wp_enqueue_block_style (WP 6.1+)
Font	theme.json settings.typography.fontFamilies (preferred) or wp_enqueue_style

Versioning for cache busting:

php

wp_enqueue_style(
    'blocksy-child-main',
    get_stylesheet_directory_uri() . '/assets/css/main.css',
    [],
    filemtime(get_stylesheet_directory() . '/assets/css/main.css')
);

Build toolchain. For non-trivial themes use @wordpress/scripts — it’s the official path, aligns with block.json toolchains, and ships sensible defaults for Webpack, Babel, ESLint, Stylelint, and Jest. Vite is workable but requires more glue.

---

12. Performance

Concern	Mitigation
Render-blocking CSS	Inline critical CSS, defer the rest
Unused Blocksy modules	Customizer → Performance → disable what you don’t use
Heavy fonts	Host locally via theme.json fontFace; use font-display: swap
Plugin CSS bloat	Conditional dequeue on routes that don’t need it
Image weight	wp_get_attachment_image with srcset, WebP/AVIF, lazy-loading (default in modern WP)
Object cache miss	Redis via Object Cache Pro or Redis Object Cache
Page cache	Server-side (Nginx fastcgi_cache) or plugin (LiteSpeed, WP Rocket, Cache Enabler)
Query bloat	pre_get_posts to limit fields, disable un-needed queries on the front page
HTTP/2 push or 103 Early Hints	Edge or origin headers; preload critical assets

---

13. Security

Concern	Mitigation in the child theme
Output XSS	esc_html(), esc_attr(), esc_url(), wp_kses_post()
Input sanitization	sanitize_text_field, sanitize_email, sanitize_textarea_field, etc.
Forms	wp_nonce_field and check_admin_referer
Capability checks	current_user_can('edit_posts') before sensitive operations
Direct file access	`defined(‘ABSPATH’)
Secrets	Never in style.css or theme.json — use wp-config.php constants or environment variables
Dashboard file editing	define('DISALLOW_FILE_EDIT', true); in wp-config.php
Auto-updates	Auto-update WP minor; plugins/themes on a schedule with a staging gate
Headers	CSP, X-Frame-Options, X-Content-Type-Options at the web-server layer
User enumeration	Block ?author=N redirects, disable XML-RPC if not used

---

14. Development and Deployment

Concern	Practice
Local dev	LocalWP, DDEV, or docker-compose
Version control	Git on the child theme; Bedrock / Composer for managing core and plugins
Migrations	WP-CLI for db/options moves; All-in-One WP Migration for ad-hoc
Staging	A separate host with prod-data refresh on schedule
CI	PHPCS (WordPress-Extra), Stylelint, ESLint, optional Playwright for visual regression
Deployment	Git pull / rsync / CI to prod; never edit theme files through the dashboard editor
Secrets	wp-config.php constants from env vars; never in the theme
Backup	Database + uploads/ + child theme repo — the other directories are reproducible

---

15. Where to Draw Lines

Don’t	Because
Edit the parent theme directly	Lost on update; ditto for plugins
Put functions in style.css	It’s a stylesheet, not a loader
Add hundreds of options to Customizer in the child	Customizer is for site config, not per-page content — use ACF or CPTs
Re-implement what Blocksy already gives you	Header builder, footer builder, archive layouts — use them
Override a template when a hook will do	Hooks survive parent updates; template copies need re-syncing
Bundle every page’s CSS into one file	Conditional enqueue per route is faster
Use <?php ?> in theme.json	It’s static JSON; for dynamic values use the wp_theme_json_data_theme filter
Inline JavaScript with <script> tags in PHP templates	Register and enqueue properly so caching, async, and CSP work

---

16. Architectural Diagram

---

17. Further Reading

• WordPress Developer Resources — Theme Handbook and Block Editor Handbook
• Blocksy documentation — creativethemes.com/blocksy/docs
• theme.json reference — Block Editor Handbook → Reference Guides
• WP-CLI handbook — wp-cli.org/
• Plugin API reference — developer.wordpress.org/plugins/hooks/

---

Reference architecture, May 2026. Verify version-specific behaviour against the WordPress core, Blocksy, and Blocksy Companion versions in your environment.
